5-19
Parameter Menus
RS-232C Port Host Options
The RS-232C port is used either as an output
RS-232C host port or as an auxiliary RS-232C
input port.
To use the RS-232C port as a host port:
1. Connect an RS-232C host device to this port.
2. Scan the Single Port RS-232C Host on page 5-15, or one
of the terminal specific RS-232C Host bar codes on pages
5-16 to 5-18.
3. Use the programming bar codes on pages 5-20 to 5-55 to
set the applicable parameters.
To use the RS-232C port as an auxiliary input port, see
page 5-56.
If you are using an RS-232C host (single or dual port)
connected to the Host port with a Synapse Smart Cable, and
you wish to change any of the host parameters, use the
Synapse parameters provided with the cable
instructions.
