Chapter 3 Using Option 001 Front-Panel Display/Keypad (58503B Only)
Status Messages
Getting Started Guide 3-11
SAT AQUIRD Normal warmup Number of satellites currently
being tracked
COARSE F ADJ Normal warmup Coarse frequency adjustment
FINE F ADJ Normal warmup Fine frequency adjustment
PHASE ALIGN Normal warmup Phase alignment
LEAPSEC CALC Normal warmup Leapsecond adjustment
OUTPUT VALID Normal warmup Outputs valid
STABILIZING Normal operation FFOM equal to 1
10MHZ STABLE Normal operation FFOM equal to 0
SURV <numeric> PCT Normal warmup Survey for position has
progressed to stated percent
completion.
<numeric> HLD USR Holdover Holdover has been manually
initiated by the user. Holdover
duration is specified <numeric>.
Note if <numeric> exceeds 99:59,
the label MAX appears.
<numeric> HLD LIM Holdover Holdover initiated when time
error between internal and
external 1 PPS signals exceeded
limit. Holdover duration is
specified <numeric>. Note if
<numeric> exceeds 99:59, the
label MAX appears.
<numeric> HLD GPS Holdover Holdover initiated on loss of GPS
satellites. Holdover duration is
specified <numeric>. Note if
<numeric> exceeds 99:59, the
label MAX appears.
<numeric> HOLDOVER Holdover Holdover for reasons other than
those identified above. Usually
on transition out of user-initiated
holdover.
HLD RECVR Recovering from Holdover Recovering from holdover
FINE F ADJ Recovering from Holdover Recovering from holdover, fine
frequency adjustment
PHASE ALIGN Recovering from Holdover Recovering from holdover, phase
alignment
Table 3-3. Status Messages (continued)
Displayed Message When Message Appears Meaning
