Synrad Firestar V Series User Manual

technical reference
82
SYNRAD OEM v40 Operator’s Manual Version 4
Firestar v40 package outline
drawings
PROPRIETARY
THIS DRAWING IS PROPRIETARY TO
SYNRAD INC. AND SHALL NOT BE
USED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT WRITTEN
PERMISSION OF SYNRAD INC.
SYNRAD INC.
4600 Campus Place Mukilteo, WA 98275 Phone: (425)349-3500 Fax: (425)349-3667
DESCRIPTION:
MATERIAL:
FINISH:
Pro/E
8.25
6.22
2.735
2.735
24.45
1.500
.625
22.633
22.445
.025
.25
11.67
3.12
2.05
22.82
.563
1.125
.800 .800
2.300
2.905 ±.010
6.21
. . . . . .xxx = ± 0.005 .xx = ± 0.01 .x = ± 0.1 ANGLE = ± 0.5 °
TOLERANCES UNLESS NOTED:
DBDESCRIPTIONDATEECOREV
REVISED NOTE ON FRONT VIEW1-Mar-063169C
DATE:APPROVED BY:
FINISH CLASS:
A
SIZE:
B
DATE:CHECKED BY:
CATEGORY:
IUNITS: INCHES
DATE: 13-Jul-01DRAWN BY:
DB: pdmdb
SHEET 1 OF 1
DWG/FILE NUMBER: 300-18565-02PART NUMBER: SEE TABLE
OUTLINE & MOUNTING, FAN-COOLED, V40
PART NUMBER MODEL
FSV40KFKEY FSV40SFOEM
NOTES: THIS MOUNTING HOLE PATTERN USED WHEN TOP ACCESS FASTENING DESIRED.
THIS MOUNTING PATTERN USED WHEN BOTTOM ACCESS FASTENING DESIRED. HARDENED BALL MOUNTING POINT, 3X
(Ø.1875 BALL BEARING) KEYSWITCH VERSION ONLY.
SEE DETAIL
A
SEE DETAIL B
1/4-20UNC
Ø.25
CONTROL I/O
KEY SWITCH
DC INPUT
W/IN-LINE FUSE
INT (GREEN)
TMP (GREEN)
READY (AMBER)
LASE (RED)
SHT (BLUE)
SHUTTER
BEAM EXIT
6X 8-32UNC ACCESSORY MOUNTING HOLES. SCREWS SHOULD NOT EXTEND MORE THAN 0.19" INTO FACE PLATE.
5V DC ACCESSORY POWER
DETAIL
A
SCALE 0.600
Ø.25
1/4-20UNC
DETAIL B SCALE 0.600
Ø.25
1/4-20UNC
1
2
3
1
2
2
1
4
4
3
4
3
3
Figure 4-19 Fan-cooled Firestar v40 package outline and mounting dimensions
