Synrad Firestar V Series User Manual

technical reference
83
SYNRAD OEM v40 Operator’s Manual Version 4
Firestar v40 package outline
drawings
Figure 4-20 Air-cooled Firestar v40 (SAB model) package outline and mounting
dimensions
PROPRIETARY
THIS DRAWING IS PROPRIETARY TO
SYNRAD INC. AND SHALL NOT BE
USED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT WRITTEN
PERMISSION OF SYNRAD INC.
SYNRAD INC.
4600 Campus Place Mukilteo, WA 98275 Phone: (425)349-3500 Fax: (425)349-3667
DESCRIPTION:
MATERIAL:
FINISH:
Pro/E
4.58
22.80
2.905 ±.010
5.76
.800
.625
2.735
2.735
6.22
22.633
24.45
1.500
22.445
.563
2.300
.800
.025
.25
1.125
. . . . . .xxx = ± 0.005 .xx = ± 0.01 .x = ± 0.1 ANGLE = ± 0.5 °
TOLERANCES UNLESS NOTED:
DBDESCRIPTIONDATEECOREV
REVISED NOTE ON FRONT VIEW1-Mar-063169B
DATE:APPROVED BY:
FINISH CLASS:
A
SIZE:
B
DATE:CHECKED BY:
CATEGORY:
IUNITS: INCHES
DATE: 10-Apr-01DRAWN BY:
DB: pdmdb
SHEET 1 OF 1
DWG/FILE NUMBER: 300-18565-01PART NUMBER: FSV40A-OEM
OUTLINE & MOUNTING, AIR-COOLED V40, OEM
NOTES:
THIS MOUNTING HOLE PATTERN USED WHEN TOP ACCESS FASTENING DESIRED. THIS MOUNTING PATTERN USED WHEN BOTTOM ACCESS FASTENING DESIRED. HARDENED BALL MOUNTING POINT, 3X. (Ø.1875 BALLBEARING)
BEAM EXIT
6X 8-32UNC ACCESSOR
Y
MTG HOLES. SCREWS
SHOULD NOT
EXTEND MORE
THAN 0.19" INT
O FACE
PLATE.
CONTROL I/O
DC INPUT
W/IN-LINE FUSE
INT (GREEN)
TMP (GREEN)
LASE (RED)
SHT (BLUE)
READY (AMBER)
SEE DETAIL
A
SEE DETAIL B
1/4-20UNC
Ø.25
DETAIL
A
SCALE 0.800
1/4-20UNC
Ø.25
DETAIL
B
SCALE 0.800
1/4-20UNC
Ø.25
1
2 3
1
2
1
2
3
3
3
