Chapter 6 Instrument Specifications
SA-90 Instructions for Use
29/
46
Chapter 6 Instrument Specifications
This chapter describes technical details about the instrument including the specifications and principles.
6.1 Specifications
Item Specification
Dimensions and
weight
Approx. 935 (W) x 1,026 (D) x 830 (H) mm, approx. 79 kg
Not including the monitor arm.
Electrical rating Voltage: AC 100 to 240 V
Frequency: 50/60 Hz
Power consumption: 100 VA or less
Protection type: Class I
Operating
environment
Operating temperature: 15 to 30 °C
Relative humidity: 30 to 85 %
Air pressure: 70 to 106 kPa
Noise level Standby: 55 dB or less
During analysis: 60 dB or less
Storage conditions Ambient temperature: -10 to 60 °C
Relative humidity: 30 to 95 % (no condensation)
Air pressure: 70 to 106 kPa
Safety standards IEC61010-1:2010, IEC61010-2-101:2015, IEC 61010-2-081:2015
