Chapter 5 Installation
SA-90 Instructions for Use
25/
46
Chapter 5 Installation
This chapter describes information required for installing the instrument.
5.1 Points to note about installation
The installation of this instrument and its related devices is handled by your authorized local representative.
Contact your authorized local representative if the instrument must be moved after it is installed.
Please note that instrument problems that occur as a result of moving the instrument yourself will be outside the
scope of the warranty, even if they occur within the warranty period.
• After the instrument is delivered, promptly check the state of the packaging.
• Leave the instrument in its packaging and place it in a dry location until it is installed. Do not place it on its side or
place it upside down.
5.2 Installation space
To ensure the accuracy and precision of the system and the safety of users, adhere to the cautions regarding the
ambient environment and power. Note the following system dimensions. To facilitate maintenance, inspection and
servicing, and to allow heat dissipation, maintain a clearance of at least 50 cm on both sides, at the back, and on top
of the instrument.
• Check the weight of the instrument and confirm that the installation location and materials can withstand that weight.
• Install the instrument in a location that is close to the power supply and a suitable drain.
• At least 2 people are required to move the instrument. To move the instrument, hold the bottom of the instrument
with two hands.
• Allow sufficient clearance for maintenance, inspection, and servicing when installing the instrument.
• The dimensions of each part of the instrument are indicated below.
Standard unit
Wagon
The dimensions and weight of the WG-90 do not include the monitor arm.
If the packaging has been damaged, promptly contact your authorized local representative.
Product name Width (mm) Height (mm) Depth (mm) Weight (kg)
SA-90 935 220 1,026 32
Product name Width (mm) Height (mm) Depth (mm) Weight (kg)
WG-90 330 830 877 47
