System Sensor D4120 User Manual

SS-300-000 7 I56-2967-000R
10
9
19
20
1
12
15
5
4
1
8
3
2
6
7
D4120
SSK451
SUP. SIGNAL
POWER +
FIELD
INSTALLED
JUMPER
11
2
+
–
AUX OUT +
AUX OUT –
ALARM
R TEST
ACC +
ACC –
R RESET
7
18
8
17
6
16
14
3
13
5
4
SUP, NO
SUP, C
NOTE: WIRING DIAGRAM SHOWN IS FOR D4120 4-WIRE DUCT SMOKE DETECTOR
SYSTEM EQUIPPED WITHOUT A CONTROL PANEL.
POWER –
COMMON
TEMPORAL SELECT
ALARM SIGNAL
TEST
RESET
FIELD
INSTALLED
JUMPER FOR
TEMPORAL
PATTERN
Figure 12. Wiring diagram for D4120 to SSK451:
H0583-00
NOTE: Wiring diagram shown is for D4120 4-wire duct smoke detector
system equipped without a control panel.
Figure 11. Wiring diagram for D4120 to RTS451/RTS451KEY:
10
9
19
20
1
12
15
2
6
1
5
4
3
D4120
RTS451/RTS451KEY
(GREEN LED) POWER
(RED LED) ALARM
FIELD
INSTALLED
JUMPER
11
2
+
–
AUX OUT +
AUX OUT –
ALARM
R TEST
ACC +
ACC –
R RESET
7
18
8
17
6
16
14
3
13
5
4
SUP, NO
SUP, C
FOR RTS451KEY ONLY WITHOUT A CONTROL PANEL
FIELD
INSTALLED
JUMPERS
H0582-00
Figure 13. Optional sensor 2 configuration and wiring:
FIELD SELECTABLE
DIP SWITCHES
TEST/RESET
BUTTON
POWER
BOARD LEDs
SENSOR
LEDs
GROUND
SCREW
SENSOR #1
TERMINALS
D4120
CO-LOCATED
WIRING TERMINALS
24V AC/DC, 10
24V AC/DC, 9
AUX OUT +, 19
AUX OUT -, 20
INT/AUX-, 1
INT+, 12
ALARM, 15
R TEST, 11
R RESET, 2
ACC -
ACC +
120 VAC
B
-
R
+
YY
B
-
R
+
Y
Y
TA MPER
TA MPER
SENSOR 1 SENSOR 2
OFF/ON TRBL SHUTDN
1/2 SENSORS
7/0 MIN TMPR DELAY
7, NO
18, C
AUX B
8, NC 17, NO
AUX A
6, C
16, NC
14, N0
3, C
13, NC 5, NO
SUPALARM
4, C
D4S
SENSOR ONLY
SENSOR #2
TERMINALS
TAMPER
Y Y R B
Y Y R B
+ –
TAMPER
+ –
SENSOR 2
D4120
D4S
NOTE: IF USING (2) D4S
SENSOR ONLY COMPO-
NENTS WITH MODEL
D4P120 POWER BOARD
COMPONENT, USE
SENSOR #1 TERMINALS
AND WIRE IN SAME
MANNER AS SHOWN FOR
SENSOR #2.
H0557-00

System Sensor D4120 Specifications

General

Model	D4120
Category	Smoke Alarm
Type	Duct Smoke Detector
Operating Temperature Range	32°F to 120°F (0°C to 49°C)
Air Velocity	300 to 4000 ft/min (1.5 to 20.3 m/sec)
Humidity Range	0% to 95% non-condensing
Compatibility	Compatible with
