D200-100-01 20 I56-3888-010
APPENDIX E
ACCESSING. INSTALLING AND RUNNING THE LATEST VERSION OF PipeIQ™
TO DOWNLOAD PipeIQ™
The latest versions of System Sensor pipe design software PipeIQ
can be found at:
www.faast-detection.com
1) Click on the Download PipeIQ button:
andthenclickon:
2) Then click on:
3) On the new screen, the user will then be able to acquire the
PipeIQ application by clicking on:
PipeIQ v2.9.x
4) SAVE the le to the PC’s Downloads folder.
TO INSTALL PipeIQ™
1) Open the PC’s Downloads folder and unzip the PipeIQ-200
2.9.x le.
2) Find the le PipeIQ Setup 2.9.x.exe and run it.
3) Follow the Install Wizard on-screen instructions through to Finish:
TO RUN PipeIQ™
The install wizard will put a PipeIQ icon on the
PC desktop when the PipeIQ setup is run.
1) Click on this icon (or nd the location of the installed PipeIQ2.exe
le and Run it). The PipeIQ conguration screen will appear.
2) Select a new project or open an existing one:
3) For a new project, choose a le name and Save it.
4) Read and acknowledge the disclaimer and click OK:
5) Select the required measurement units and click OK:
6) Select the aspirating unit to be used and click OK:
7) It is now possible to design an aspirating pipe network, or
congure and monitor an aspirating device. A Help button is
available in the Toolbar to assist with understanding the range
of operations and options that are available.
Any earlier version of PipeIQ that has been installed on the PC will
be upgraded to version 2.9.x
