System Sensor FAAST LT User Manual

D200-100-00
5
I56-3888-005
FURTHER PIPEIQ™ CAPABILITIES
Creating a Project
To create a project select New from the File menu or click on the
toolbar.
The New Project dialog box appears.
In the File Name box, type the name of the project, and then click
Save.
The PipeIQ™ project le is created.
A project can comprise a site, buildings, oors, and devices. When
creating a project, these items are created by default; they must
be dened before designing the pipe layout. For information on
conguring elements on a site, see the PipeIQ™ Help (select
PipeIQ™ Help from the Help menu.
Note: It is possible to add new buildings, oors and devices to
a project after the initial site conguration is complete. Editing or
modifying a project is carried out in the Conguration mode; for
more information on adding elements to a project, refer to the
PipeIQ™ Help Menu.
Designing a Pipe Layout
To create an effective layout, the designer must have knowledge
of the following:
Local codes and standards for the site
Pipe network design
Creating layouts using drawing packages (e.g. AutoCAD
®
software)
and similar tools producing DXF format les.
For more information on using the Pipe Design Application Tools,
see the PipeIQ™ Help Menu.
Creating Reports
PipeIQ™ can generate the following reports.
Conguration Reports
Event Log Report
Pipe Layout
Bill of Materials.
For more information on using the Report options, see the PipeIQ™
Help Menu.
PipeIQ™ Help
The online help is a guide through the PipeIQ™ application. The
Help opens in a separate window where it is possible to search and
navigate to information on different topics.
Select PipeIQ™ Help from the Help menu or press F1. When you
press F1 the help topic for the active window is invoked.
Using Help - Navigation Pane (Left Pane)
This pane includes Contents, Search and Index tabs. Click on the
tab to access the content of each.
Index: This tab contains a multilevel list of keywords and keyword
phrases. To open a topic in the Display pane (Right pane) associated
with a keyword, double click the keyword. If the keyword is used in
more than one topic, a dialog box is displayed so you can select
the topic to view, and then click Display or double-click the topic.
Search: This tab helps you to search for a topic or content. Type
the word to search and press Enter on the keyboard. The list of
topics is displayed below. Double click the topic to show it in the
Display pane.
Contents: This tab lists the Table of Contents that contains
categorized books and pages. When you double click a closed
book it opens to display its topics, and when you click an open
book it closes. Double click a topic to show it in the Display pane.
Using Help - Display Pane (Right Pane)
The Display pane on the right of the online help displays the
content for the selected topic.
Blue Underlined Text Indicates a link to a different topic.
Green Italicized Text Indicates a link to more information or
images in the same topic. Re-click the link to hide the information
or image.
