A1: FAAST LT CONFIGURATION PARAMETERS
All the FAAST LT congurable parameters are described in Table
A1 below. The default values set into the unit at manufacture are
listed in Tables A2 and A3. The user can change parameter values
using the PipeIQ™ application software that runs on a PC and
then upload the new conguration into the unit.
SA denotes a Stand Alone unit
LB is a Loop Based (addressable) unit
A a denotes applicable
APPENDIX A
FAAST LT CONFIGURATION PARAMETERS AND DEFAULT SET-UP VALUES
Table A1: FAAST LT Conguration Parameters
# PARAMETER
PARAMETER
RANGE
SA LB DESCRIPTION COMMENTS
1 Maintenance Password 1111 - 9999
 
4 digit code required to enable front panel
push buttons and access Maintenance
mode.
Factory default password 3111.
2 Current configuration
number
0..255
 
Number used to identify the current device
configuration. Every time the configuration is
changed, this number is incremented.
Factory default is 1.
When 255 is reached the
number rolls back to 0
3 Current configuration
date
DD/MM/YY
HH:MM:SS
 
Date/Time of last device configuration
upload.
4 Channel 1 enabled YES/NO
 
YES: Channel is enabled and operating as a
smoke detector.
NO: Channel is disabled.
Only possible with 2 channel
units; cannot disable both
channels at the same time.
5 Channel 2 enabled YES/NO
 
6 Sensor 1 enabled YES/NO
 
YES: Sensor is enabled and operating as a
smoke detector.
NO: Sensor is disabled
For 1 channel + 2 sensor version
only; not possible to disable both
sensors.
7 Sensor 2 enabled YES/NO
 
8 Daylight saving enabled YES/NO/AUTO
 
Allows the real time clock date to change for
a daylight saving period (+1 hour)
NO: Daylight saving off. YES:
period is specified by parameters
9 and 10.
AUTO: sets start date to last
Sunday in March and end date
to last Sunday in October.
9 Daylight saving start
date
DD/MM HH:MM
 
Start date/time of daylight saving period Used when daylight saving is set
to YES.
10 Daylight saving end
date
DD/MM HH:MM
 
End date/time of daylight saving period
11 Disable time 1..240 min
 
When disabled the device stops reporting
alarms and faults for this period.
When the time expires or
RESET is pressed, device
returns to Normal state.
12 Maintenance timeout 1..30 min or 0 (Not
Used)
 
Sets the period of inactivity after which a unit
will return to Normal from Maintenance
mode
In remote maintenance (USB
connected) there is no device
timeout.
13 Trend log interval 1..240 min or 0 (Not
Used)
 
Time interval used by a device to regularly
record its status.
Events are also logged as they
occur.
14 Sensors blinking
replicated
YES/NO
 
NO: No blink
YES: Channel alarm LED blinks green when
the detector is in Normal state.
When channel is in alarm, the
alarm LED will change to red.
15 Both supplies monitored YES/NO
 
NO: Only power supply #1 input is
monitored.
YES: Power supply #2 is also monitored
16 Common chamber
sensors required for
alarm
1,2
 
Detector alarm logic for common chamber
model (1 channel x2 sensors):
1. OR function – either sensor in alarm
2. AND function – both sensors need to be
in alarm.
If a sensor is disabled or in fault,
this parameter is ignored.
17 Sounder automatic cut-
off time
0 (Not Used),
5,10,15,…,600 s
 
Sounders turn off after this time period,
following activation.
