SystemAir Danvent TIME - Copy of the Label with Information about Connection of Cables

To Next Page

To Previous Page



Annex9—3



Restartofrotor:

‐ Switchoffpowerandswitchonpoweragain

or

‐ Pressthetestbuttoninsidethecabinet



Testofmotor bycheckingtheresistanceinall3vindings

Motorsizes Ohm

90TYD‐S214‐M 40Ω

120TYD‐S214‐M 18Ω

120TYD‐S214‐L 10Ω



Settingofconstantspeed:

‐ SetfourthDIPswitchleverinposition‐ON



Test:

‐ SetfourthDIPswitchleverinposition–ON

‐ Pressthetestbutton



9.1.3Copyofthelabelwithinformationaboutconnectionofcables

Thisself‐adhesivelabelisalwaysplacedonthecover

ofthecabinet.ThetextisalwaysinEnglish.




