8.6Foambandsbetweenrailsandroofplates–mountroofplates.

PlacefoambandsPbetweenprofilesA1,B2,C3,D4androofplates.



Thetrapezoidalroofplatesaremountedwiththeself‐drilling,paintedscrewssuppliedwithsealingwasher.

8.7Foambandsbetweenroofplates

Mounttheself‐adhesivefoamband–O‐ontheunderlappingribforwaterresistantandeffectivesealing

duetothesmallslopeoftheroof.



8.8Mountroofplates–someofthemareoverlappingby2ribs

Thewidthofeachplateisalways1.035mmandsomeoftheplateshavetooverlapby2ribstoachievethe

optimaltotallengthofthewholeroof—seetheillustrationabove.

8.9Mountoverhangprofile–G5ontheotherendoftheunit.

Whenthelasttrapezoidalplate(inthisexampleF5)hasbeenplacedontheunit,thesecondroofoverhang

profileG5mustbepushedunderthetrapezoidalroofplateandmountedwiththeself‐drilling,painted

screwwithsealingwasher.Mountingmustbesimilartothemountingofroofoverhangprofile

underthe

trapezoidalroofplateattheotherendoftheunit.
