12 Technical data
12.1 Technical data overview
Max. temperature of transported air, °C
Refer to the data sheet in the online catalogue at www.systemair.com.
Max. ambient temperature, °C
Sound pressure, dB
IP class
Voltage, current, frequency, enclosure
class, weight
Refer to the name plate. Refer to 1.5 Name plate page 4 for more information.
Motor data Refer to the motor name plate or the technical documentation from the motor
manufacturer.
12.2 Product dimensions
12.2.1 Product dimensions DVN fans and DVNI fans
Note:
If the unit of measure is not specified, the dimensions are given in millimetres.
F
G
A
B
H
L
I
J
E
M
C
D
K
A B C D E F G H I J ØK ØL
(4x)
M
DVN 355
720 618 600 390 M8
(6x)
438 450 200 M20-
x1.5
200 438 12
(4x)
18.5
DVN 400
720 618 600 390 M8
(6x)
438 450 200 M20-
x1.5
200 438 12
(4x)
18.5
DVN 450
900 730 675 465 M8
(6x)
438 535 273 M20-
x1.5
273 438 12
(4x)
18.5
DVN 500
900 730 675 465 M8
(6x)
438 535 273 M20-
x1.5
273 438 12
(4x)
18.5
DVN 560
1150 955 900 560 M8
(8x)
605 750 293 M20-
x1.5
293 605 14
(4x)
20
DVN 630
1150 955 900 560 M8
(8x)
605 750 293 M20-
x1.5
293 605 14
(4x)
20
17
