SystemAir DVN 355

A B C D E F G H ØI ØJ
DVS 190
370 320 175 335 6xM6 335 245 M20x1.5 213 10(4x)
DVS 225
370 320 175 335 6xM6 335 245 M20x1.5 213 10(4x)
DVS 310
560 470 330 435 6xM6 435 330 M20x1.5 285 10(4x)
DVS 311
560 470 330 435 6xM8 435 330 M20x1.5 285 10(4x)
DVS 315
560 470 330 435 6xM8 435 330 M20x1.5 285 10(4x)
DVS 355
720 618 390 595 6xM8 595 450 M20x1.5 438 12(4x)
DVS 400
720 618 390 595 6xM8 595 450 M20x1.5 438 12(4x)
DVS 450
900 730 465 665 6xM8 665 535 M20x1.5 438 12(4x)
DVS 500
900 730 465 665 6xM8 665 535 M20x1.5 438 12(4x)
DVS 560
1150 960 565 939 6xM8 939 750 M20x1.5 605 14(4x)
DVS 630
1150 960 565 939 6xM8 939 750 M20x1.5 605 14(4x)
DVS 710
1350 1185 660 1035 6xM8 1035 840 M20x1.5 674 14(4x)
DVSI 190
498 438 210 335 6xM6 335 245 M20x1.5 213 10(4x)
DVSI 225
498 438 210 335 6xM6 335 245 M20x1.5 213 10(4x)
DVSI 310
695 584 370 435 6xM8 435 330 M20x1.5 285 10(4x)
DVSI 311
695 584 370 435 6xM8 435 330 M20x1.5 285 10(4x)
DVSI 355
877 745 440 595 6xM8 595 450 M20x1.5 438 12(4x)
DVSI 400
877 745 440 595 676 595 450 M20x1.5 438 12(4x)
DVSI 450
970 825 479 665 676 665 535 M20x1.5 438 12(4x)
DVSI 500
970 825 479 665 676 665 535 M20x1.5 438 12(4x)
DVSI 560
1315 1130 600 939 676 939 750 M20x1.5 605 14(4x)
DVSI 630
1315 1130 600 939 676 939 750 M20x1.5 605 14(4x)
DVSI 710
1483 1185 729 1035 676 1035 840 M20x1.5 674 14(4x)
12.2.3 Product dimensions DVC-S fans and DVCI-S fans
Note:
If the unit of measure is not specified, the dimensions are given in millimetres.
19
