SystemAir DVN 355 - Page 46

2
1
3
4
5
6
9
8
7
10
1. VKS: Back draft damper
2. SSD: Roof curb
3. ASK: Inflow box SSD
4. VKS: Back draft damper
5. ASS: Flexible connection
6. ASF: Inlet flange
7. FTG: Tilting device
8. TDA: Adapter framework
9. VKM: Back draft damper (motor operated)
10. FDS: Flat roof curb
