1.4 Product overview
1.4.1 Product overview MUB/T fans and MUB/T-S fans
4
1
2
9
7
8
3
5
6
1. Casing
2. Motor (inside casing on MUB/T fans and MUB/T ECO
fans)
3. Motor connection box
4. Fan impeller
5. Name plate
6. Air flow direction arrow
7. Safety switch (not applicable for MUB/T ECO fans)
8. Electrical supply connection (not applicable for MUB/T
ECO fans)
9. Drain plug
