MenuLevel1MenuLevel2MenuLevel3Explanation
Service
Functions
Functions
Heater/Cooler
Heater/Cooler
Preheater:YES/NO
Reheater:
None/Electrical/Wa-
ter/Other
Cooler:None/Water
Usethisdialogueframetoset
uptheunitforheatingand/or
cooling.
SetYEStoactivate
preheater.Defaultsettingis
NO.
Note:
Ifpreheaterisactivatedand
heatexchangercontrolis
setto“On/Off”,itishighly
recommendedtochoose
defrostlevel0toavoid
conictswithdefrosting
functions.
SetRe-heatertoNone,
Electrical,WaterorOther.
Note:
IfreheaterissettoOther,
externalheaterisonly
controlledbyAO1(0–10V).
Overheatorfrostprotection
isnotavailable.
SetCoolertoNoneorWater.
Functions
Temp.Control
Temp.control
P-band:5°C
I-time:OFF
Output:0–100%
Usethisdialogframeto
adjustthesettingsofsupply
airtemperaturecontroller.
Settheproportionalband
(P-band)rangeforPI
controller.Defaultvalue5°C.
Setintegraltime(I-time)
rangeforPIcontroller.
DefaultvalueOff.
Showsoutputsignal
presentedforthesupply
airtemperaturecontroller.
Functions
Exchanger
Control
Exchangercontrol
On/Off/Variable
Usethisdialogframetoselect
heatexchangercontroller
type.
SetOn/Offtoactive
temperaturecontroland
defrostingbasedondefrost
levels0–5.
SetVariabletoactivate
temperaturecontroland
moisturetransfercontrol(if
available).
SAVEVTR200/BInstallationandService
208061
24
SystemairSverigeAB
