Functions
Preheater
Pre-Heater
PreheaterSp:-30–
0°C)
P-band:5°C
Output:Auto(xx%)/
Man(Off/On)
Usethisdialogframeto
congurepre-heaterfunction.
Congurethesetpoint
setting.Defaultvalueis
dependantonsystemtype.
Incounterowunitssetpoint
isnotadjustable.
Settheproportionalband
(P-band)rangeforPI
controller.Defaultvalue5°C.
SetoutputtoAutoorMan.
DefaultsettingisAuto.Actual
controlleroutputsignalis
presentedinautomode.
SelectingMan,enablesthe
usertomanuallycontrol
outputofthepreheater
(On/Off).
Functions
Frostprotection
Frostprotection
Alarmlimit:7°C
Showscurrentsetfrost
protectionalarmlimitin°Cfor
theinstalledwatercoil.
SetAlarmlimitin°C.
Defaultvalue:7°C.
Functions
Systemcurve
Systemcurve
EF:1–10
SF:1–20
Thisfunctionisto
compensatetheow
valuesfordifferentsystem
pressures.
Seechapter7.3
Functions
Fancontrol
Fancontrol
Airflow
Systemcurve
%
Selectthetypeoffancontrol
youprefer.Fancontrolbyl/s,
m
3
/hor%
Fancontrol
Airflow
Airflow
l/s
Nom
High
Low
EF
44
67
26
SF
44
67
26
Usethisdialogueframeto
settheairowinl/s.The
airowcanbesetindividually
foreachfan
EF:Extractfan,
SF:Supplyfan
SettheairowforEFandSF
foreachstep(Low,Nom,and
High.
Systemcurveshallonlybe
availableincaseasystem
withthattypeoffancontrol
isused.
Fancontrol
Airflowunit
Airflowunit
l/s/m
3
/h/%
Defaultvalue:l/s
SAVEVTR200/BInstallationandService
208061
25
SystemairSverigeAB
