T Scale T-Touch VX7-11 - Page 8

T-Touch Retail Application A1.10
- 6-
Printer : X7-11_J7-11
General Specification
Paper Roll loading or unloading
Printer: Paper Cut
1. Lift the lever and pull out until the
cover group is released
2. Open Cover
3. Load / unload Paper rolls
4. Close Cover group, Press both
side to close correctly
5. Pull the paper towards the Tear
Bar from one side to the other
