TA Instruments TGA55 - Unpacking the Balance

Discovery TGA™ Getting Started Guide Page 29
Unpacking the Balance
After removing the bracket, you can proceed to unpack the balance. This very important procedure must
be completed before you can use the Discovery TGA.
1 Carefully remove the balance housing cover by loosening the screws.
Figure 10 Removing the balance housing cover.
2 Loosen the thumbscrews and remove the balance cover shown in the figure below.
Figure 11 Loosen thumbscrews.
