tae TA-U65 User Manual

Instruction and Operating Manual
TA-U1...U280
Misprints and technical changes reserved
40
5.3.2 Encoder RS422
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
+5V
+24V Out
AGND
0V
supply voltage encoder +0V GND
Signal A
Signal A
(invert)
Signal U
Signal V
Signal W
(invert)
Zero pulse Z1
(invert)
Zero pulse Z2
Zero pulse Z2
(invert)
Zero pulse Z1
+24V
GND
supply voltage encoder +5V
Signal B
Signal B
(invert)
Signal U (invert)
Signal V (invert)
Signal W
UD-Encoder PCB
(RS422) - 402
for TA-U...
45 46 47 48 49 50 51444342
Zero point master signal Z1
Com Z1
Zero point slave signal Z2
Com Z2
A
B
Com
TAE Motor terminal box
S1-1 S1-2 S1-3
GND
GND GND
GND
GND
*)
Temperature evaluation 1
*)
Temperature evaluation 2
Klixon = Switch-OFF
PT100 = Te mperature indicator, pre-
warning and switch-OFF pre-
seted with software
KTY84130 = Temperature indicator, pre-
warning and switch-OFF pre-
seted with software
Klixon = Pre-warning
PT100 = Te mperature indicator, pre-
warning and switch-OFF pre-
seted with software
KTY84130 = Temperature indicator, pre-
warning and switch-OFF pre-
seted with software
A
B
Com
Reference
Reference
actual value
output
conductance
input
Encoder or
Initiators for
angle Synchronization
14
13
15
12
16
5
6
7
8
9
11
3
4
1
2
10
WH/YE
BN/GN
WH/GN
YE/BN
BU
RD/BU
GY/PK
YE
GN
WH
BN
VT
BK
PK
GY
RD
P1
P3
P2
RD
WH
Temperature evaluation 1
Temperature evaluation 2
Option
