tae TA-U65 User Manual

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 4
03: Drive Data
ID
Name
Value-Range
Default-Value
Unit
Access
69
Pulse Frequency Max Threshold
1,000 ... 20,000
3,000
Hz
RC
70
Pulse Frequency Hysteresis
1,000 ... 20,000
5,000
%
RC
71
Start Frequency
1,00 ... 12,00
1,80
kHz
RC
72
Increase Frequency-Ramp
0,000 ... 100,000
---
Hz
R
73
Increase Speed-Ramp
1,0 ... 1500,0
---
rpm
R
74
Switch-Off Peak Current
1,000 ... 1000,000
---
A
RC
75
Controller Speed Limit
1,0 ... 15000,0
3900,000
rpm
RC
76
Controller Current Limit
0,000 ... 1000,000
---
A
RC
80
Current Calibration
100,00 ... 3000,00
---
A
R
81
Speed Calibration
1000,00 ... 15000,00
---
rpm
R
82
Current Calibration negative
-3000,00 ... 100,00
---
A
R
83
Speed Calibration negative
-15000,00 ... 1000,00
-1500,00
rpm
R
04: Machine Data
ID
Name
Value-Range
Default-Value
Unit
Access
90
Machine Speed Factor
0 ... 100000
---
--
RW
91
Machine Speed Divisor
1 ... 100000
---
--
RW
92
Machine Torque Factor
0 ... 100000
1
--
RW
93
Machine Torque Divisor
1 ... 100000
1
--
RW
94
Machine Tension Factor
0 ... 100000
1
--
RW
95
Machine Tension Divisor
1 ... 100000
1
--
RW
97
Machine Speed
0,000 ... 2147483647,000
---
--
R
98
Machine Torque
0,000 ... 2147483647,000
---
Nm
R
99
Machine Tension
0,000 ... 2147483647,000
---
N
R
05: Drehzahl/Strom
ID
Name
Wertebereich
Standardwert
Einheit
Zugriff
100
Dig. Speed-Set
0,0 ... 1000,0
0,0
rpm
RW
101
Max Speed
0,0 ... 1000,0
100,0
rpm
RW
102
Min Speed
0,0 ... 1000,0
0,0
rpm
RW
103
Torque-Set
0,0 ... 200,0
100,0
%
RW
104
Max Current Accel (1Q)
0,00 ... Par.67
Par.66
A
RW
105
Max Current Decel (4Q)
0,00 ... Par.67
0,00
A
RW
106
Motor working load
0,0 ... 500,0
---
%
RC
107
Drive working load 1Q
0,0 ... 500,0
---
%
RC
108
Drive working load 4Q
0,0 ... 500,0
---
%
RC
109
Overload time
1,00 ... 1000,00
1,00
s
RW(0)
110
Speed Preset 1
0,0 ... 1000,0
0,0
rpm
RW
111
Speed Preset 2
0,0 ... 1000,0
0,0
rpm
RW
112
Speed Preset 3
0,0 ... 1000,0
0,0
rpm
RW
113
Speed Preset 4
0,0 ... 1000,0
0,0
rpm
RW
114
Speed Preset 5
0,0 ... 1000,0
0,0
rpm
RW
115
Speed Preset 6
0,0 ... 1000,0
0,0
rpm
RW
116
Speed Preset 7
0,0 ... 1000,0
0,0
rpm
RW
