APPENDIX
A
Specifications
NOTE: Specifications are subject to change without any prior notices.
Parts Specifications
CPU
Intel Pentium M processor LV, 1.1 GHz in µ-FCBGA package
FSB (Front Side Bus) 400 MHz, thermal ceiling 12 W
L2 Cache Memory 1 MB on-die
ROM BIOS 512 KB Flash EEPROM (system and VGA BIOS), Plug-and-Play
capability, ACPI 2.0 capability, boot from IDE devices / LAN / USB
optical drive, Suspend-to DRAM/HDD support, PC2001-compliant
System One 200-pin PC2100 DDR SO-DIMM socket (200/266 MHz),
256 MB SDRAM (standard), up to 1 GB
RAM
Shared video Up to 64 MB
Panel 10.4-inch TFT XGA LCD (touchscreen), resolution up to 1024×768,
sunlight readable (transflective) – option
Video controller Integrated into Intel 855GM, integrated 32-bit 3D/2D gfx core with
Dynamic Video Memory technology, supports DirectX® 8.1 and AGP
4×, dual view function, LCD/CRT simultaneous display capability
Display
Video port VGA port via optional Port Replicator or Vehicle Docking Station
modules
Keyboard (external/wireless) Waterproof membrane (rubber) keyboard or
IP54 ruggedized keyboard with backlight function – option,
standard keys, numeric keypad, 12 function keys, and Windows keys
Pointing device Touch-sensitive LCD panel with Microsoft WinMouse function
coexisting / digitizer panel LCD
Floppy disk drive 3.5-inch, 1.44 MB (via optional USB FDD module on Expansion port)
Hard disk drive Integrated 2.5-inch, 9.5 mm height, IDE, Ultra DMA-33/66/100
support with damper protect
Storage
device
Optical drive CD/Combo/DVD-RW (via optional module on Expansion port)
Audio controller Realteck ALC202 codec, AC97 support, MS-Sound compatibility,
built-in mono speaker
Audio
Audio port Two audio ports for Mic-in / Line-out
