11.6 Motor Valve Control
Function Diagram
Motor valve
FY600/800/900
COM
R
Controller
RC RC
CLOSE
CLOSE
7 6
no
OPEN
8 9
feedback
(NFMV)
OPEN
10
COM
S
ball valve：Low pressure, general use
needle valve ： High pressure, High precision use
Motor valve
FY600/800/900
Controller
CLOSE
14 CLOSE
1KΩ
COM
15 WIPER
signal feedback
OPEN
16 OPEN
COM
R
RC RC
CLOSE
CLOSE
feedback
7 6
(FBMV)
OPEN
8 9
OPEN
10
COM
S
ball valve：Low pressure, general use
needle valve ： High pressure, High precision use
※ It is recommended to install spark killer at the relay junction to prolong the service life of the relay.
Spark killer connection
Motor valve
spark killer
COM
FY600/800/900
Controller
CLOSE
CLOSE
67
A
C spark killer
NEPO NEPO
98
10
COM
