18 Multitone Paging Interface Fitting Instruction
© Tait Electronics Limited July 2008
6. Check the RJ45 communications using the TB7100 programming
application to interrogate the Tx.
1.14 Final System Check
1. Set the default options on the Programmable I/O form in the Digital
tab set as per the following table.
2. Enable the following Digital Action Parameters: Alarm on Out Of
Lock, Alarm on High Temperature, Alarm on Very High
Temperature and Alarm on High Reverse Power.
3. Set all Key Settings to none.
4. On the SI board place W300 (Tx / Rx GPIO 5) Link (“Link
positions on the SI board” on page 16.
Pin Direction Label Action Active Debounce
Signal
State
Mirrored
To
AUX_GPI1 Input RT_DI_1 BCD Pin 0 Low 10 None None
AUX_GPI2 Input RT_DI_2 BCD Pin 1 Low 10 None None
AUX_GPI3 Input RT_DI_3 BCD Pin 2 Low 10 None None
AUX_GPIO4 Output HI_VSWR Alarm Status Low None None None
AUX_GPIO5 Output OOL Alarm Status Low None None None
AUX_GPIO6 Output HI_TEMP Alarm Status Low None None None
AUX_GPIO7 Input TXKEY External PTT 1 Low 2 None None
IOP_GPIO1 None PIN_9 No Action High None None None
IOP_GPIO2 None PIN_10 No Action High None None None
IOP_GPIO3 None PIN_11 No Action High None None None
IOP_GPIO4 None PIN_12 No Action High None None None
IOP_GPIO5 None PIN_13 No Action High None None None
IOP_GPIO6 None PIN_14 No Action High None None None
IOP_GPIO7 None PIN_15 No Action High None None None
CH_GPIO1 None C_HEAD No Action High None None None
To Next Page
