24 General Specifications TM9400 Specifications Manual
© Tait Limited November 2016
Figure 4.3 Connectors of the graphical control head
front view
rear view with adapter flange
microphone
connector
control-head
connector
Figure 4.4 Dimensions of radio with remote body interface (25W radio shown)
7.48 in. (190 mm) / 8.27 in (210 mm)*
2.07 in. (52.61 mm)
*Mobile radios >25 W are
0.79 in. (20 mm) longer
due to a larger heatsink
7.08 in. (179.8 mm) / 7.87 in (199.8 mm)*
Other dimensions are as shown in Figure 4.5 on page 25
