6-6
TROUBLESHOOTING
IF A FUSE BLOWS
If a light does not come on or the electrical
system does not work, a fuse may be blown.
Inspect the fuses.
INSPECTING AND REPLACING THE FUSE
If the fuse blows again soon after
replacement, then the electric system is
likely faulty. It may pose a fire hazard if
not properly repaired. Contact your sales
or service dealer for advice.
1. Turn the starter key to the OFF position to
stop the engine.
2. Open the engine hood.
IF A FUSE BLOWS
3. Open the fuse box cover (1).
4. Check for any blown fuses.
5. If a fuse is blown, replace it with a spare
fuse of the same capacity.
Fuse layout and circuits protected
Capacity Symbol
Protected
circuit
10A Horn
30A
Engine stop
solenoid
20A Boom light
10A Hour meter
15A Lever lock
3A Feed pump
To Next Page
