3-12
OPERATION
OPERATING THE TRAVEL LEVERS
• Never allow anyone to enter the
machine’s slewing radius and path.
• Signal your intention to move by
sounding the horn.
• There is a blind spot in the rear of the
machine. Before traveling in reverse, as
necessary, swing the cab around in
reverse to check that the area is safe
and clear.
OPERATING THE MACHINE
AG7A032PE
Dozer blade
• Before operating the travel levers, make
sure that the dozer blade is to the front
of the operator’s seat. Remember that
when the dozer blade is to the rear of
the operator’s seat, the travel levers
must be operated in the reverse
direction from when the blade is to the
front.
• Clear all obstacles from the path of the
machine.
1. Pull the throttle lever and increase the
engine speed.
2. Fully lower the safety lock lever to
disengage the lock.
3. Fold the hoe attachment and lower it 30 to
40 cm (12 to 16 in.) above the ground.
4. Lift the dozer blade.
5. Operate the left and right travel levers as
below.
Moving the machine forward and
backward
