8-9
OPTIONS
TRAVEL ALARM
TRAVEL ALARM
The alarm sounds while the machine is
traveling and stops when the machine stops
traveling.
If the alarm does not sound when the
machine travels, the fuse may be blown.
Inspect the fuses.
If the fuse blows again soon after
replacement, then the electric system is
likely faulty. It may pose a fire hazard if
not properly repaired. Contact your sales
or service dealer for advice.
1. Turn the starter key to the OFF position to
stop the engine.
2. Open the engine hood.
3. Open the fuse box cover (1).
4. Check for fuse.
5. If a fuse is blown, replace it with a spare
fuse of the same capacity.
Fuse layout and circuits protected
Capacity Symbol
Protected
circuit
10A Horn
30A
Engine stop
solenoid
20A
Boom light,
Travel alarm
10A Hour meter
15A Lever lock
3A Feed pump
To Next Page
