7-7
SPECIFICATIONS
MACHINE DIMENSIONS
Unit: mm (inch)
Item Rubber crawlers
A Overall length 2955 (116.3)
B Upperstructure overall width 750 (29.5)
C Overall height 2190 (86.2)
D Slew radius 610 (24.0)
E Clearance height under upperstructure 395 (15.6)
F Crawler base 1005 (39.6)
G Crawler overall length 1325 (52.2)
H Crawler overall width (narrow) 750 (29.5)
H
2
Crawler overall width (wide) 1020 (40.2)
J Crawler shoe width 180 (7.1)
K Ground clearance of undercarriage 160 (6.3)
L Minimum radius of equipment and attachment 1320 (52.0)
M Minimum radius of equipment at maximum front offset 1165 (45.9)
P Offset distance of bucket (Right swing) 390 (15.3)
Q Offset distance of bucket (Left swing) 440 (17.4)
R Dozer blade width (narrow) 750 (29.5)
R
2
Dozer blade width (wide) 1020 (40.2)
S Dozer blade height 200 (7.9)
T Front distance to axis of rotation 2245 (88.5)
U Dozer blade distance to axis of rotation 930 (36.6)
V Boom swing angle (Right) 55°
W Boom swing angle (Left) 55°
X Overall length (canopy is folded) 3415 (134.4)
Y Overall height (canopy is folded) 1475 (58.1)
Limited boom swing angle type
