Takeuchi TCR50 User Manual

146
SPECIFICATIONS
Main Specifications
ENGINE
Manufacturer and model ISUZU 4JJ1X
Rated output kW / min
–1
(hp / rpm) 72 / 2200 (96.6 / 2200)
Displacement mI (cu.in.) 2999 (183)
Starter V – kW 24 – 4
Alternator V – kW 24 – 1.2
Battery V – A·h 12 – 54 x 2
MASS
Operating mass kg (lb.) 6025 (13285)
PERFORMANCE
TYPE CAB
Dump body capacity m
3
(cu.ft.) Heaped 2.055 (72.57)
(standard dump body) Struck 1.15 (40.61)
Maximum loading mass kg (lb.) 3700 (8155)
Swing speed min
–1
(rph) 180° 6.6 (6.6)
Travel speed km / h (mph) 0~9.2 (5.72)
Gradeability (degrees) 30
Ground pressure
with Dump body Full 33.3 (4.84)
kPa (psi)
with Dump body Empty 20.4 (2.96)
Noise level dB (A)
Sound-power level L
WA
103
Sound-pressure level L
pA
—

Takeuchi TCR50 Specifications

General

Brand	Takeuchi
Model	TCR50
Category	Construction Equipment
Language	English
