54
CONTROLS
Levers
Control Levers
WARNING
Be careful to check which pattern of lever
control arrangement you are operating
with before beginning operations.
1. Right Control Lever
Use the right control lever to operate the
dump body.
Refer to page 73 “Operating the Dump
Body”.
2. Left Control Lever
Use the left control lever to travel the
machine.
Refer to page 70 “Traveling the
Machine”.
Safety Lock Lever
WARNING
Before leaving the operator’s seat, set
the safety lock lever to the lock position
and stop the engine. If any controls
should be touched accidentally when
the safety lock lever is lowered, the
machine will move suddenly, and
cause serious injury or death.
Be careful not to touch the control
levers when raising and lowering the
safety lock lever.
This device is for locking the dump body
movement and machine travel.
When the lever is lifted and the lever stand
springs up, the control levers are locked.
To Next Page
