42
CONTROLS
Fuel Filler Cap
WARNING
Do not smoke or permit open
flames while fueling or near fueling
operations.
Supply fuel in a well ventilated place
and with the engine stopped.
Clean up spilled fuel immediately.
Do not fill the fuel tank to capacity.
Allow room for expansion.
Tighten the fuel filler cap securely.
Opening
1. Open the keyhole cover, insert the key
and turn it counterclockwise to unlock the
fuel cap.
2. Turn the fuel cap counterclockwise and
remove it.
Closing
1. Set the fuel cap in place and turn it
clockwise.
2. Turn the key clockwise to lock the fuel
cap, then remove the key.
Raised Body Prop
WARNING
If you must work beneath the raised dump
body, securely engage the raised body
prop. Never get under the dump body if it
is not sufficiently supported.
Engaging the raised body prop
1. Fully raise the dump body.
2. Set the safety lock lever to the lock
position and stop the engine.
3. Pull up the ring and remove the lock pin
(1), then remove the pin (2).
4. Put the disconnected end of the prop (3)
between the lock holes and insert the pin
(2).
5. Install the lock pin (1) and push down the
ring.
Disengaging the raised body prop
1. Move the right control lever to raise the
dump body.
2. Disengage the prop (3) and put it back in
place.
Doors and Covers
To Next Page
