Tally Dascom DL-200 - Product Configuration

Tally Dascom DL-200 User Guide V1.3
9
1.6 Product Configuration
Interface Types

USB interface (USB2.0, Full speed)
 Serial interface: Serial port (RS-232, DB25)
 Parallel interface: Bidirectional parallel port (IEEE1284)

LAN interface: Ethernet (10Base-T, 100Base-TX)
 Wireless LAN interface: Wi-Fi (802.11b/g)
 Bluetooth interface (BT 3.0/4.0+EDR, SPP)
Model
Interfaces
Power
Cord
Paper Cut
Sensor
USB
PAR
SER
ETH
Wi-Fi
Bluetooth
EN/UK/EU
Cutter
Tear
Bar
Black
Mark
DL-200
√
O
O
O
O
O
√
O
√
√
Remarks: “√” indicates standard configuration, “O” indicates optional configuration.
PAR=Parallel interface; SER= Serial interface; ETH=Ethernet interface.
The optional interfaces are not available as switchable boards.
They are only orerable as a separate model in combination with the USB interface:
-
USB only
-
USB + SER
-
USB + PAR
-
USB + ETH
-
USB + Wi-Fi
-
USB + BT
Optional Interface
(Serial/ Parallel/ Ethernet/
Wi-Fi/ Bluetooth）
USB interface
