2.6 Loading Transfer Ribbon
Transfer ribbons come in several varieties and in some cases colors to match your application needs.
The media and ribbon types should be matched to provide you with optimal print results. Always use
ribbon that is wider than the media to protect the printhead from wear.
For direct thermal printing, do not load ribbon in the printer.
Do not use ribbon while using direct thermal media. Otherwise, barcode
and graph will be distorted.
(1) Lift the top cove.
(2) Unwrap the ribbon roll pack and separate the
ribbon roll and the bare paper core.
