Align the part “A” on the left side of the Ink-ribbon Cartridge
to the two hooks of the printer, push the cartridge all the way
until it clicks. If there is resistance, push it while turning the
Ribbon Feed Knob.
Detach the Ribbon Guide from the Ink-ribbon Cartridge.
Put the Ribbon Guide between the Print Head and the Platen
and push it all the way until it clicks.
Turn the Ribbon Feed Knob in the direction indicated by the
arrow to remove any slack in the ribbon.
Hooks
Part “A” (left side)
Ink-ribbon
cartridge
Ribbon Feed Knob
Do not detach the shield that has been attached to the
Ribbon Guide; it is necessary to protect the ribbon.
When attaching the Ribbon Guide, be careful not to
fold the ribbon. Also, pay attention to the shield so
that it does not become damaged.
Ribbon Feed
Knob
ENGLISH
Quick start-up Installing the ribbon cassette
9
