Tally T2240 - Quick Start-up; Paper Thickness Adjustment; Access Cover Removal; Print Head Positioning

Installing the
ribbon cassette
Remove any paper loaded into the printer.
Before opening the cover, make sure that the printer is switched off.
Set the Paper Thickness Adjustment Lever to the “8” position.
Pull the Latch Levers near the right and left ends on the Access
Cover to the front, and detach the entire Access Cover.
Move the Print head to approximately the center.
STOP
Paper Thickness
Adjustment Lever
Access Cover
Latch Lever
Latch Lever
Print head
The Print Head may be hot. So please be careful not
to touch the metal part of the Print Head.
STOP
Installing the ribbon cassette Quick start-up
8
