Fig. 4: Rear view of Model MPC-102L
10 A
I N
Circuit
Protector
RS-232C
Connector
Coolant outlet
Coolant inlet
Si
g
nal cable
Power cable
Power cord
Coolant circulation device (OUT)
(To water tap)
Coolant circulation hose (with insulation pipe)
OUT
Coolant circulation device (IN)
(To water drain)
Coolant circulation hose (with insulation pipe)
AC Outlet
MPC-102L Only
MPC-102L Onl
y
MPC-102L Onl
y
