- 33 -
Optional Accessories:
・ Extension cables (power and signal) 3m
⇒ For use when the control unit and test unit are located separately
・ Printer Model BS2-80TS made by Sanei Electric (connected to the
RS-232C output port)
⇒ Prints pour/cloud point test results and Expected pour/cloud points
Paper Size: 80 mm wide, ∅38 mm, 15 m long (Paper Roll)
One roll can store 250 tests
(No details printed in PP/CP mode)
Power Supply: AC Adapter Input: 100-120or 220-240 VAC,
50/60 Hz, 20 W max
Output: DC 6V, 1500 mA
Dimensions and Weight: 134(W) x 60(H) x 180(D)mm/ approx. 450g
Included Parts: Connection cable……….1 m
Paper Roll………………. 1 roll
・ Clock board (Mounted on the main board in the control unit)
⇒ Necessary for printing test dates and times when the printer is
connected
・Coolant circulation device for MPC-102L (Recommended by Tanaka Scientific Limited)
Model : TCU-40 Ultra-low temperature bath circulator made by Tanaka Scientific Limited.
Bath Capacity: Approx. 8.0L
Power Supply: 120 or 220-240 VAC 50/60 Hz 500W
Dimensions and Weight: 320(W) x 590(D) x 725(H) mm Approx. 60.0 kg
・Water pressure regulator with pressure gauge: Necessary when a tap water line is connected
instead of coolant circulation device(s).
*Pressure regulator: Pressure regulator valve with a lock
*Pressure gauge: 0-400kPa. (Normally set at 50kPa.)
