Maintenance, Service, and Repair
Brakes Page 15
REPLACE FRONT BRAKE PADS
NOTE: It is recommended that both the left and right brake pads be replaced
as a set.
1. Make sure the key-switch is in the “OFF” position, then remove the
key.
2. Place the forward-reverse switch in the center “OFF” position.
3. Set the park brake.
4. Place blocks under the rear wheels to prevent vehicle movement.
5. Disconnect the main positive and negative cables at the batteries.
Current Taylor-Dunn
®
brakes are asbestos free. However, there is the
possibility that the original brakes were replaced with aftermarket
parts containing asbestos. Since this possibility exists, all brake parts
should be handled as if they contain asbestos. Refer to appendix C
for recommended handling precautions.
NOTE: Installing new brake pads will raise the brake fluid level in the master
cylinder.
6. Thoroughly clean the area around the master
cylinder cap.
7. Remove fluid from the master cylinder until it is 1/2
full.
Always use a lifting strap, hoist, and jack stands, of adequate capacity
to lift and support the vehicle. Failure to use lifting and support devices
of rated load capacity may result in severe bodily injury.
8. Raise the front of the vehicle and support with jack
stands.
9. Remove the tire/wheel assembly. Refer to Tires and Wheels section for information on removing
the tire and wheel assembly.
