Taylor-Dunn MX-016-00 - Page 189

Illustrated Parts
PARTS PAGE 5
Steering Linkage
ITEM # PART # DESCRIPTION QTY
1 86-518-01 Rod end (LH) 1
2 -- - -
3 86-510-00 Ball Joint Clamp 2
4 - - -
5 50-002-03 Drag Link 1
6 88-119-81 3/8-NF Hex Locknut 2
7 88-159-85 1/2-NF Hex Castle Nut 2
8 86-501-98 Ball Joint (left thread) 1
9 18-041-05 Tie Rod Sleeve (18-057-20 assembled with ball jointsand clamps) 1
10 86-501-99 Ball Joint (right thread) 1
11 86-518-00 Rod End (RH) 1
12 88-279-82 7/8-NF Hex Jam Nut 1
13 18-640-00 Pitman Arm 1
14 88-268-62 7/8 Split Lock Washer 1
15 88-527-11 1/8 x 1 Cotter Pin 2
16 97-202-50 3/8-NF Left Thread Nut 1
17 88-119-80 3/8-NF Hex Nut 1
