Taylor-Dunn MX-016-00 - Service Limits

Motor Service
Motor
Page 7
SERVICE LIMITS
Motor Specification
Number
Undercut Depth
Commutator Diameter
(min)
Brush Length
(min)
Wire Depth
(max)
mm inches mm inches mm inches mm inches
5BC58JBS6129A 0.635 0.025 66.75 2.625 19.05 0.75 38.1 1.5
5BC58JBS6129B 0.635 0.025 66.75 2.625 19.05 0.75 38.1 1.5
5BC58JBS6129C 0.635 0.025 66.75 2.625 19.05 0.75 38.1 1.5
5BC49JB399C 0.635 0.025 78.97 3.109 19.05 0.75 - -
5BC58JBS6110C 0.635 0.025 78.97 3.109 19.05 0.75 38.1 1.5
