29
Models 104 & 220
Parts
Model 104 Parts Identification
ITEM DESCRIPTION PART NO.
1 SHELL A.-INSULATED X33380
1a BEARING-REAR SHELL 031324
1b WASHER-BEARING LOCK 012864
1c NUT-BRASS BEARING 028991
1d GUIDE-DRIP SEAL 028992
2 SHIELD-MIX-GEAR REDUCER 013356
3 GEAR A.*REDUCER 4.21:1 012235
4 PULLEY-AK74 X 5/8 051013
5 BELT-V-4L420 004338
6 SHROUD-CONDENSER 051035
7 DRYER-FILTER-HP62-3/8 X 1/4S 048901
8 VALVE-EXP-AUTO-1/4S X 1/4 047232
9 CONDENSER-AC-12LX16HX2.5 048935
10 VALVE-ACCESS 1/4FL X 3/8 044455
11 VALVE-ACCESS-1/4 MFLX1/4 047016
12 SCREW-5/16-18 X 1-3/4 HEX 019691
13 WASHER-5/16-FLAT ZP STEEL 000651
14 SLEEVE-MOUNTING-COMP-AE 039920
15 GROMMET-COMPRESSOR MT 039919
16 NUT-5/16-18·MF·LOCK 017327
17 SWITCH-PRESSURE 440 PSI 048230
18 COMPRESSOR
AKA9462ZXD-AK172E
049302-
ITEM DESCRIPTION PART NO.
19 BRACKET-FAN 051036
20 BOX-SPLICE 051053
21 COVER-SPLICE BOX 011858
22 SUPPORT-SHELL 051037
23
FAN-5 BLADE 12” PUSH 22 _ C
049009
24 MOTOR-FAN 50 WATT 029770-
25 GUIDE A.-DRIP PAN X51048
26 PANEL A.-FRONT X51043
27 KNOB-TIMER 030343
28 LIGHT-ORANGE-ROUND 017450
29 SWITCH-ROCKER-AUTO/EJECT 049628
30 SEAL-PANEL-ROCKER SWITCH 048421
31 STUD-FREEZER DOOR 023057
32 MOTOR-1HP 60HZ 115/208-230 034097-
33 PULLEY-AK30 X 5/8 033559
34 COVER-CONTROL BOX 051056
35 CONTROL A. (See Pg. 38) X49827-
36 BEZEL 033406
37 COVER A.-MIX INLET X24948
38 SUPPORT-INLET COVER 027449
39 BUMPER-RUBBER 15/64”HOLE 031667
40 GASKET-BASE·PAN 049420
41 PIN-INLET COVER 027464
To Next Page
