Taylor 220 Service Manual

Parts List
+ Available Separately
42
Parts List Models 104 & 220
110908
DESCRIPTION PART
NUMBER
104
QTY.
W ARR.
CLASS
REMARKS PARTS
UPDATE
ACTUAT OR--INTERLOCK 034342 1 103 INTERLOCK SWITCH
+BRACKET--INTERLOCK SWITCH 034341 1 103 +E--RING 1/4 032190 1 000 +SPRING--COMP.480X.034X2.00 SS 029889 1 103 +SWITCH--ROLLER--SPDT--20A--125--480 025444 1 103
BEARING--REAR SHELL *NICKEL PLATE 031324 1 000
+GUIDE--DRIP SEAL 028992 1 000 +NUT--BRASS BEARING 028991 1 000 +WASHER--BEARING LOCK 012864 1 000
BEATER A. X33417 1 103
+BLADE--SCRAPER 17L 033277 2 000
BEL T--V--4L420 004338 1 000 BLOCK--TERMINAL 2P--L1,N 039421 1 103 1 15V 60HZ 1PH BLOCK--TERMINAL 2P--L1,L2 039422 1 103 208--230V 60HZ 1PH BLOCK--TERMINAL 7 POLE 022606 1 103 BRUSH--DRAW VALVE 1--1/2”OD X 3” 014753 1 000 BRUSH--MIX PUMP BODY--3”X7”WHITE 023316 1 000 BRUSH--REAR BRG 1IN.DX2IN.LGX14 013071 1 000 BUMPER--RUBBER 15/64”HOLE--WHITE 031667 1 000 BUZZER 120V 022758--12 1 103 1 15V 60HZ 1PH BUZZER 240V/5W 022758--27 1 103 208--230V 60HZ 1PH COMPRESSOR AKA9462ZXA--AK1 049302--12 1 512 1 15V 60HZ 1PH -- TECUMSEH
+CAPACITOR--RUN-- 25UF/370VAC 023739 1 103 +CAPACITOR--START-- 72--88UF/250V 039557--27 1 103 +RELAY--START--COMPRESSOR 045432--12 1 103
COMPRESSOR AKA9462ZXD--AK1 049302--27 1 512 208--230V 60HZ 1PH
+CAPACITOR--RUN-- 15UF/370V 027087 1 103 +CAPACITOR--START-- 72--88UF/330V 039567 1 103 +RELAY--START--COMPRESSOR 048150 1 103
CONDENSER--AC--12LX16HX2.5T3ROW 048935 1 103 COVER A.--MIX INLET X24948 1 103
+PIN--INLET COVER 027464 1 103 +SUPPORT--INLET COVER 027449 2 103
DOOR A.--PARTIAL X37710 1 103
Model 104
