Taylor 220 Service Manual

30
Parts
Models 104 & 220
Model 104 Panels Exploded View
ITEM DESCRIPTION PART NO.
1 PANEL-SIDE *L 051039
2 HOOD A. X51044
3 PANEL-REAR 051040
4 PANEL-SIDE *R 051038
5 SCREW-10-32X3/8·TRUSS·HD 024298
ITEM DESCRIPTION PART NO.
6 HINGE·COVER·ASSY·ADAPTOR 037707
7 PANEL A.-FRONT X51043
8 PAN-DRIP 13-1/4 LONG 039027
9 DECAL-DEC 051046-60
10 STUD-FREEZER DOOR 023057

Taylor 220 Specifications

General

Brand	Taylor
Model	220
Category	Freezer
Language	English
