38
Parts
Models 104 & 220
120127
Control A. X62460--27 (Model 104)
ITEM DESCRIPTION PART NO.
1 RELAY--START--COMPRESSOR 048150
2 SCREW --8X1/4 SLTD HEX 009894
3 SCREW --6X3/8 SLTD HEX 001825
4 BUZZER 240V/5W 022758--27
5 SWITCH--ROLLER --SPDT--20A 025444
6 SCREW --6--32X7/8 SLOTTED 007017
7 BLOCK --TERMINAL 7P 20A 300 022606
8 TIMER--INTERVAL 30MIN 230 030324 --27
ITEM DESCRIPTION PART NO.
9 RELAY --DPDT--20A--120/240/277 026581--27
10 CONNECTOR--BX 3/8 STR
--2 SCREW
014569
11 CAPACITOR--RUN 15UF/370V 027087
12 CAPACITOR--START 72--88UF 039567
13 STRAP--CAPACITOR 5--5/8 IN. 030258
14 SCREW--8--32X1/4 SLOTTED 000953
