Taylor 220 Service Manual

+ Available Separately
44
Parts List Models 104 & 220
DESCRIPTION PARTS
UPDATE
REMARKSW ARR.
CLASS
104
QTY.
PART
NUMBER
MOTOR--1 HP -- BEATER 034097-- 1 212 MOTO R--FAN 50 WATT W/GROUND 029770--12 1 103 1 15V 60HZ 1PH MOTO R--FAN 50 WATT W/GROUND 029770--27 1 103 208--230V 60HZ 1PH
+FAN--5 BLADE 12” PUSH 22DEG CCW 049009 1 103 +BRACKET--FAN 051036 1 103
NUT--STUD 008614 2 103 HANDSCREWS PAIL--6 QT . 023348 1 000 PAN--DRIP 13--1/4 LONG 039027 1 103 PANEL A.--FRONT *104* X51043 1 103 PANEL--REAR *104* 051040 1 103 PANEL--SIDE *104*L* 051039 1 103 PANEL--SIDE *104*R* 051038 1 103 PULLEY--AK30 X 5/8 033559 1 103 BEATER MOTOR PULLEY--AK74 051013 1 103 GEAR RELAY--3 POLE--25 AMP 067460--12 1 103 1 15V 60HZ 1PH RELAY--DPDT--20A--120/240/277V 026581--27 1 103 208--230V 60HZ 1PH -- S/N K6035924 & UP RELAY--SPDT 032607--27 2 103 S/N K6035923 & PRIOR SANITIZER--STERA SHEEN --GREEN 055492 1 000 SHAFT--BEATER 033498 1 103
+SEAL--DRIVE SHAFT 032560 1 000
SHELL A.--INSULATED *103* X33380 1 512
+STUD--FREEZER DOOR *103--232* 023057 2 103
SHIELD --MIX--G EAR REDUCER 3--3/8” 013356 1 103 SWITCH--PRESSURE 440 PSI--SOLDER 048230 1 103 SWITCH--ROCKER AUTO/EJECT 049628 1 103
+SEAL--PANEL--ROCKER SWITCH 048421 1 000
SWITCH--ROLLER -- 20A.--125--4 025444 1 103 TIMER--INTERVAL30MIN115 030324--12 1 103 1 15V 60HZ 1PH TIMER--INTERVAL 30MIN 230V 030324--27 1 103 208--230V 60HZ 1PH
+KNOB--TIMER 030343 1 103
VALVE--ACCESS 1/4FL X 3/8SDR--90 044455 1 103 MAIN LOW SIDE VALVE--ACCESS--1/4 MFLX1/4 S--90 047016 1 103 MAIN HIGH SIDE VALVE--EXP--AUTO--1/4S X 1/4FPT 047232 1 103
+BOOT--EXPANSION VALVE 027137 1 000
VARIST OR A.--280VAC X34664 2 103 208--230V 60HZ 1PH
