Taylor 220 Service Manual

+ Available Separately
48
Parts List Models 104 & 220
DESCRIPTION PARTS
UPDATE
REMARKSW ARR.
CLASS
104
QTY.
PART
NUMBER
FUNNEL 034252 1 103
+BEZEL 033406 1 103
GASKET--BASE PAN 049420 1 000 GEAR A.*REDUCER 012235--SER 1 212 MAYBAR ONLY GUIDE A.--DRIP P AN *104*HP62* X51048 1 103 HINGE COVER ASSY ADAPTOR 037707 1 103 HOOD A. *104* X51044 1 103 INSTRUCTION--INSTALL--CHINESE 056904CINS 1 000 KIT A.--TUNE UP*103* X33275 1 000
CHART--O--RING SIZE--70# PAPER 032530 1 000 O--RING--2--1/4 OD X .139W 030890 1 000 O--RING--5 7/16 OD X 5 1/4 ID 033276 1 000 SEAL--DRIVE SHAFT 032560 1 000 TOOL--O--RING REMOVAL--FREEZER 048260--WHT 1 000
LABEL--ATTN SVC ENG--CHINESE 015068--CH 1 000 LABEL--COPPER COND ONLY--AS 025948--AS 1 000 LABEL--WARN--ELEC--SGL--SMALL 032717--CH 1 000 LABEL--DOOR--MOVE PART--CHINESE 032749--CH 1 000 LABEL--WARN--COVER--CHINESE 051433--CH 4 000 LIGHT--ORANGE--ROUND 017450 1 103 LUBRICANT--TAYLOR 4 OZ. 047518 1 000 MAN--OPER COND 104 CHINESE 053064CM 1 000 MOTOR--1HP 50HZ 220--240V 1425RP 034097--34 1 212 220--240V 50HZ 1PH MOTOR--FAN 50 WATT W/GROUN 029770--27 1 103 220--240V 50HZ 1PH
+FAN--5 BLADE 12” PUSH 22DEG CCW 049009 1 103 +BRACKET--FAN 051036 1 103
NUT--STUD 008614 2 103 HANDSCREWS O--RING--1--1/4 OD X .139W 008667 1 000 PAIL--6 QT . 023348 1 000 PAN--DRIP 13--1/4 LONG 039027 1 103 PANEL A.--FRONT *104* X51043 1 103 PANEL--REAR *104* 051040 1 103 PANEL--SIDE *104*L* 051039 1 103 PANEL--SIDE *104*R* 051038 1 103 PULLEY--AK30 X 5/8 033559 1 103 BEATER MOTOR
Model 104
