Models 754/8754 Specifications
Freezing Cylinder
Two, 3.4 quart (3.2 liter) volume.
Mix Hopper
Two, 20 quart (18.9 liter) capacity.
Beater Motor
Two, 1.5 hp.
Refrigeration Unit
Two, approximately 9,500 btu/hr compressors.
Refrigerant R404A.
One independent (SHR) compressor, approximately
400 btu/hr. Refrigerant R134a.
(BTU's may vary based on compressor used.)
Electrical
Two dedicated connections.
Maximum Minimum Circuit
Electrical
Fuse Size Ampacity
Model 754 Left Right Left Right
208-230/60/1 Air 35 30 26 22
208-230/60/1 Water 30 30 24 22
208-230/60/3 Air 25 20 19 15
208-230/60/3 Water 20 20 17 15
Model 8754
208-230/60/1 Air 35 30 28 24
208-230/60/1 Water 35 30 25 24
208-230/60/3 Air 25 20 21 17
208-230/60/3 Water 25 20 18 17
These units are manufactured in other electrical
characteristics. Refer to the Distributor Data Book for
availability. (For exact electrical information, always refer to
the data label of the unit.)
Air Cooled
Clearance: 3" (7.6 cm.) around all sides. A deflector has
been added to underside preventing recirculation of warm air.
This will assure proper air flow across condensers to obtain
optimum performance.
Water Cooled
Water inlet and drain connections under side of base 1/2"
FPT.
Dimensions
Width: 26-7/16" (67.2 cm.)
Depth: 33" (83.8 cm.)
Height: 59-7/8" (152.1 cm.)
Floor Clearance: 7-1/2" (19.1 cm.) mounted on
standard casters.
Approximate Weights
Model 754:
Net: 680 Ibs. (308.4 kgs.) Crated: 707 Ibs. (320.7 kgs.),
47.3 cu. ft. (1.34 cu. m.)
Model 8754:
Net: 730 Ibs. (331.1 kgs.) Crated: 768 Ibs. (348.4 kgs.),
47.3 cu. ft. (1.34 cu. m.)
Availability and specifications are subject to change
without notice.
These units are designed and constructed to meet stringent
safety and sanitation requirements for NSF and UL.
