Model 774 Specifications
Freezing Cylinder
Two, 3.4 quart (3.2 liter) volume.
Mix Hopper
Two, 20 quart (18.9 liter) capacity.
Beater Motor
Two, 1.5 hp.
Refrigeration Unit
Two, approximately 9,500 btu/hr compressors.
Refrigerant R404A.
One independent (SHR) compressor, approximately
400 btu/hr. Refrigerant R134a.
(BTU's may vary based on compressor used.)
Electrical
Two dedicated connections.
Maximum Minimum Circuit
Fuse Size Ampacity
Electrical
Left
Right Left Right
208-230/60/1 Air 35 30 28 22
208-230/60/1 Water 35 30 25 22
208-230/60/3 Air 25 20 21 15
208-230/60/3 Water 25 20 18 15
This unit is manufactured in other electrical characteristics.
Refer to the Distributor Data Book for
availability. (For exact electrical information, always refer to
the data label of the unit.)
Air Cooled
Clearance: 3" (7.6 cm.) around all sides. A deflector has
been added to underside preventing recirculation of warm air.
This will assure proper air flow across condensers to obtain
optimum performance.
Water Cooled
Water inlet and drain connections under side of base 1/2"
FPT.
Dimensions
Width: 26-7/16" (67.2 cm.)
Depth: 36-3/16" (91.9cm.)
Height: 59-7/8" (152.1 cm.)
Floor Clearance: 7-1/2" (19.1 cm.) mounted on
standard casters.
Approximate Weights
Net: 760 Ibs. (344.7 kgs.) Crated: 865 Ibs. (392.4 kgs.),
49.7 cu. ft. (1.3 cu. m.)
Availability and specifications are subject to change
without notice.
This unit is designed and constructed to meet stringent safety
and sanitation requirements for NSF and UL.
